Description:

The perfect choice for professional landscape contractors who want the innovative engineering and commercial-grade quality of a Lazer Z zero turn riding mower, but in a value package. It features the same welded, heavy-duty, 1.5”x 3” tubular steel unibody frame found throughout our Lazer Z models. You can also choose from two rugged Kawasaki® V-Twin engines or a Kohler® Command™ EFI engine matched to a full-floating, UltraCut™ Series 4 cutting deck, in 48, 52, 60- or 72-inch widths. A digital operator diagnostic module simplifies system monitoring and troubleshooting, while the fuel gauge uses ultrasonic waves to provide a more accurate reading. Comes equipped with a full-suspension seat that enhances operator comfort.

Features:

Our hydro drive system has no hoses to leak and just one easy-to-change belt
Only simple, annual maintenance is required. It also lowers the center of gravity for improved handling
Gas-powered E-Series models have a single 8-gallon tank with one fill location
Fewer Grease Points
Rear Discharge Deck
Unibody Frame
Check vital functions at a glance on the digital screen
This full-floating deck uses maintenance free spindle with a splined blade driver to stop bolt tightening on impacts
Deck and hydro belt can be installed without using any tools

Specification:

Engine:

Brand: Kawasaki
Model: FX651V
Displacement: 726 cc
Series: V-Twin
Speed: 3,750 RPM
Fuel System: Carbureted
Fuel Type: Gas Carbureted
Fuel Capacity: 12 gallons (45.4 L)
Air Filter: Heavy-duty canister air filtration system
Engine Spec: FX651V-FS07-R

Transmission:

Type: Hydrostatic
Speeds: Infinitely Variable
Drive: Hydro-Drive
Drive Description: Two Exmark exclusive Parker unitized pump and wheel motor systems with no hoses, 1.7-quart integrated reservoir, spin-on filter, and heavy-duty components. 12 cc pumps and 14.5 cubic inch motors.

Tires:

Front Caster Tires: 13 x 5.0-6, smooth-tread, semi-pneumatic
Drive Tires: 23 x 9.50-12, 4 ply Super Turf®

Deck:

Width: 48 inches
Style: Floating Deck
Style Description: Full-floating UltraCut Series 4. Side discharge standard, with molded discharge chute and option to bag or mulch.
Construction: 10-gauge top that is formed and continuously seam welded, 7-gauge side skirt and 7-gauge reinforced spindle mounting locations for improved strength and reduced weight.
Cutting Heights: 1.0" (2.5 cm) to 5.5" (11.8 cm) in 0.25" (0.64 cm) increments adjustable from operator’s seat.
Blade Tip Speed: Approximately 18,500 fpm
Blades: 3 Blades at 16.25" Length

Safety:

Package: Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators
Parking Brake: Lever-actuated disc brake
ROPS: 2-post foldable ROPS standard with seat belt and latch

Additional Features:

Starter: Electric
Steering Control: Hydraulically dampened twin levers, adjustable both fore and aft. Also has 2-position height adjustment.
Seat: Deluxe, bolstered suspension seat with Elastomeric Vibration Control material. Adjustment: Fore and aft from operator’s position.
Standard Features: Engine hour meter; cup holder
Deck Lift: Standard; foot-controlled deck lift changes cutting height and lifts the deck to maneuver around obstacles or place in transport position
PTO Engagement: MagStop Electromagnetic 175 ft-lb clutch with spot brake
Drive Wheel Release: Allows unit movement without engine running
Fuel Indicator: Yes - electronic Sender
Carb Compliant: No
